ASE2P-6M-10-Z
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
Standard ASE Through Hole Right Angle Tray Slide Switch 2.80mm 50mA 60V 70-500gf
PDF
/
Inventory: 8987
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 2.80mm
Technical
Switch Travel 2.20mm
Contact Timing Non-Shorting (BBM)
Operating Force 70 ~ 500gf
Throw Configuration DPDT
Electrical Life 10,000 Cycles
Contact Style Non-Shorting
Switch Function On-Off-On
Circuit DPDT
Actuator Type Standard
Voltage - Rated AC 60V
Termination Style PC Pin
Contact Finish Gold
Current Rating 50mA
Current Rating (Amps) 50mA AC/DC
Voltage - Rated DC 60V
Min Operating Temperature -20°C
Max Operating Temperature 85°C
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Washable
Series ASE
Published 2016
Packaging Tray
Operating Temperature -20°C~85°C
Physical
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Plating Gold
Supply Chain
Factory Lead Time 9 Weeks
