EG2324

E-Switch
RoHS
RoHS RoHS compliant
Package /
Category Switches / Slide Switches
Description SWITCH SLIDE DP3T 300MA 30V
PDF
/
Inventory: 6672
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Actuator Length 7.00mm
Width 9mm
Length 21mm
Height 11.5mm

Technical

Switch Travel 2.50mm
Contact Function ON-OFF
PCB Hole Count 12
Contact Timing Not Specified
Illumination Type Non-Illuminated
Operating Force 300/400gf
Switch Type SLIDE SWITCH
Dielectric Withstanding Voltage 500VAC V
Insulation Resistance 100000000Ohm
Contact Resistance 0.02mOhm
Switch Function On-On-On
Circuit DP3T
Actuator Type Standard
Termination Style PC Pin
Contact Finish Silver
Current Rating 300mA
Orientation Right Angle
Current Rating (Amps) 300mA DC
Voltage - Rated DC 30V
HTS Code 8536.50.90.50
Number of Positions 8
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series EG
Published 2002
Packaging Bulk
Operating Temperature -20°C~70°C

Physical

Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material Copper Alloy
