EG2305
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
Standard EG 2 Through Hole Slide Switch 4.00mm 200mA 30V 250/300gf
PDF
/
Buying Options
Total Price: USD $0.96
Unit Price: USD $0.9592
≥1 USD $0.9592
≥10 USD $0.92224
≥100 USD $0.634418
≥500 USD $0.590163
≥1000 USD $0.497948
≥3000 USD $0.461067
Inventory: 9789
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole
Technical
Operating Temperature -20°C~70°C
Packaging Bulk
Published 2002
Series EG
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Number of Positions 2
HTS Code 8536.50.90.50
Voltage - Rated DC 30V
Current Rating (Amps) 200mA DC
Orientation Vertical
Current Rating 200mA
Contact Finish Silver
Termination Style PC Pin
Voltage - Rated AC 30V
Body Breadth 6.8 mm
Actuator Type Standard
Circuit DP3T
Switch Function On-On-On
Electrical Life 10000 cycles
Switch Type SLIDE SWITCH
Contact Current Rating 200mA
Operating Force 250/300gf
Illumination Type Non-Illuminated
Contact Timing Not Specified
Switch Travel 2.00mm
Dimensions
Width 6mm
Body Height 4.7mm
Actuator Length 4.00mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
