EG1260ASQ
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
SWITCH SLIDE SPDT 300MA 4V
PDF
/
Inventory: 8704
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Copper Alloy
Mount Surface Mount
Mounting Type Surface Mount, Right Angle
Technical
Operating Temperature -20°C~70°C
Packaging Tape & Reel (TR)
Published 2004
Series EG
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
ECCN Code EAR99
HTS Code 8536.50.90.50
Voltage - Rated DC 4V
Current Rating (Amps) 300mA DC
Current Rating 300mA
Contact Finish Silver
Termination Style Gull Wing
Contact (DC) Max Rating R Load .3A@4VDC
Contact Timing Shorting (MBB)
Operating Force 150gf
Switch Type SLIDE SWITCH
Mechanical Life 10,000 Cycles
Electrical Life 10,000 Cycles
Contact Voltage(DC)-Max 4V
Contact Current(DC)-Max 0.3A
Contact Style Shorting
Switch Function On-On
Circuit SPDT
Actuator Type Standard
Body Breadth 2.7 mm
Body Length or Diameter 6.7mm
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 1.50mm
Body Height 1.4mm
