500SSP1S1M7REA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
SWITCH SLIDE SPDT 0.4VA 20V
PDF
/
Buying Options
Total Price: USD $4.4
Unit Price: USD $4.403467
≥1 USD $4.403467
≥189 USD $1.75666
≥504 USD $1.698893
≥1008 USD $1.670009
Inventory: 1121
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Copper Alloy
Mount Through Hole, Vertical
Mounting Type Through Hole, Right Angle, Vertical
Housing Material STAINLESS STEEL
Actuator Material Polyamide (PA), Nylon
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2004
Series 500
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Number of Positions 2
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Orientation Vertical
Current Rating 400mA
Contact Finish Gold
Termination Style PC Pin
Voltage - Rated AC 20V
Body Length or Diameter 12.7mm
Body Breadth 6.604 mm
Actuator Type Standard
Circuit SPDT
Switch Function On-On
Contact Resistance 0.1mOhm
Insulation Resistance 1000000000Ohm
Electrical Life 30,000 Cycles
Mechanical Life 30,000 Cycles
Switch Type SLIDE SWITCH
Contact Current Rating 5A
Contact Current(AC)-Max 2A
Contact (AC) Max Rating R Load 2A@250VAC
Contact Timing Not Specified
Contact Voltage(AC)-Max 250V
PCB Hole Count 5
Switch Travel 2.16mm
Dimensions
Body Height 7.6962mm
Length - Termination 0.156 inch
Actuator Length 4.72mm
Compliance
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
