500SDP1S4M1QEB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
SWITCH SLIDE DPDT 5A 120V
PDF
/
Buying Options
Total Price: USD $7.85
Unit Price: USD $7.849829
≥1 USD $7.849829
≥200 USD $3.132579
≥500 USD $3.027547
≥1000 USD $2.976344
Inventory: 5653
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Copper Alloy
Mount Panel
Mounting Type Panel Mount
Insulation Material DIALLYL PHTHALATE
Housing Material STAINLESS STEEL
Actuator Material Polyamide (PA), Nylon
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2008
Series 500
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Number of Positions 1
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Current Rating 5A
Contact Finish Silver
Termination Style Solder Lug
Voltage - Rated AC 120V
Body Length or Diameter 12.7mm
Body Breadth 11.43 mm
Actuator Type Standard
Circuit DPDT
Switch Function On-On
Contact Resistance 0.01mOhm
Insulation Resistance 1000000000Ohm
Contact Current(DC)-Max 5A
Dielectric Withstanding Voltage 1000VRMS V
Electrical Life 30,000 Cycles
Mechanical Life 30,000 Cycles
Switch Type SLIDE SWITCH
Contact Current(AC)-Max 2A
Contact (AC) Max Rating R Load 2A@250VAC
Contact Timing Not Specified
Contact Voltage(AC)-Max 250V
Switch Travel 2.16mm
Dimensions
Body Height 7.62mm
Actuator Length 3.56mm
Compliance
RoHS Status ROHS3 Compliant
