500SDP1S2M7QEA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
Standard 500 1 Through Hole Right Angle Vertical Slide Switch 6.88mm 5A 1000VRMS V 5A@120VAC
PDF
/
Buying Options
Total Price: USD $9.13
Unit Price: USD $9.133845
≥1 USD $9.133845
≥200 USD $3.64461
≥500 USD $3.522511
≥1000 USD $3.46343
Inventory: 5532
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Copper Alloy
Mount Through Hole, Vertical
Mounting Type Through Hole, Right Angle, Vertical
Insulation Material DIALLYL PHTHALATE
Housing Material STAINLESS STEEL
Actuator Material Polyamide (PA), Nylon
Technical
Operating Temperature -30°C~85°C
Packaging Bulk
Published 2012
Series 500
Feature Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Number of Positions 1
Voltage - Rated DC 28V
Current Rating (Amps) 5A AC/DC
Current Rating 5A
Contact Finish Silver
Termination Style PC Pin
Voltage - Rated AC 120V
Body Length or Diameter 11.43mm
Body Breadth 12.7 mm
Actuator Type Standard
Circuit DPDT
Switch Function On-On
Contact Resistance 0.01mOhm
Insulation Resistance 1000000000Ohm
Contact Current(DC)-Max 5A
Dielectric Withstanding Voltage 1000VRMS V
Electrical Life 30,000 Cycles
Mechanical Life 30,000 Cycles
Switch Type SLIDE SWITCH
Contact Current(AC)-Max 5A
Contact (AC) Max Rating R Load 5A@120VAC
Contact Timing Not Specified
PCB Hole Count 8
Switch Travel 2.16mm
Dimensions
Body Height 20.8788mm
Length - Termination 0.125 inch
Actuator Length 6.88mm
Compliance
RoHS Status ROHS3 Compliant
