GI-154-0055
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
Standard GI 1 Through Hole Right Angle Slide Switch 5.08mm 3A 125V 3A@125VAC
PDF
/
Inventory: 3225
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 5.08mm
Length - Termination 0.219 inch
Body Height 10.541mm
Technical
Switch Travel 3.94mm
Actuator Color BLACK
Contact (DC) Max Rating R Load 0.5A@125VDC
Contact Timing Not Specified
Contact (AC) Max Rating R Load 3A@125VAC
Contact Current(AC)-Max 3A
Switch Type SLIDE SWITCH
Mechanical Life 10,000 Cycles
Electrical Life 6,000 Cycles
Contact Current(DC)-Max 0.5A
Contact Resistance 0.01mOhm
Switch Function On-On-On
Circuit DP3T
Actuator Type Standard
Body Breadth 7.62 mm
Body Length or Diameter 30.226mm
Voltage - Rated AC 125V
Termination Style PC Pin
Contact Finish Silver
Current Rating 3A
Current Rating (Amps) 3A AC 500mA DC
Voltage - Rated DC 125V
Number of Positions 1
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series GI
Packaging Bulk
Operating Temperature -10°C~104°C
Physical
Actuator Material Polyamide (PA66), Nylon 6/6
Housing Material COLD ROLLED STEEL
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material Copper
Supply Chain
Factory Lead Time 12 Weeks
