GF-165-0001
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
SWITCH SLIDE 3PDT 500MA 125V
PDF
/
Inventory: 4705
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Copper
Mount Panel
Mounting Type Panel Mount, Right Angle
Housing Material COLD ROLLED STEEL
Actuator Material Polyamide (PA66), Nylon 6/6
Technical
Operating Temperature -10°C~104°C
Packaging Bulk
Published 2016
Series GF
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Number of Positions 1
Voltage - Rated DC 125V
Current Rating (Amps) 500mA AC/DC
Current Rating 500mA
Contact Finish Silver
Termination Style PC Pin
Voltage - Rated AC 125V
Body Length or Diameter 25.4mm
Body Breadth 7.62 mm
Actuator Type Standard
Circuit 3PDT
Switch Function On-On
Contact Resistance 0.01mOhm
Contact Current(DC)-Max 0.5A
Electrical Life 6,000 Cycles
Mechanical Life 10,000 Cycles
Switch Type SLIDE SWITCH
Contact Current(AC)-Max 0.5A
Contact (AC) Max Rating R Load 0.5A@125VAC
Contact Timing Not Specified
Contact (DC) Max Rating R Load 0.5A@125VDC
PCB Hole Count 9
Actuator Color BLACK
Switch Travel 3.61mm
Dimensions
Body Height 14.4018mm
Length - Termination 0.219 inch
Actuator Length 5.08mm
Compliance
RoHS Status ROHS3 Compliant
