V80202MS02Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
Switch Slide DPDT Extended Top Slide 10A 250VAC 30VDC PC Pins Thru-Hole
PDF
/
Buying Options
Total Price: USD $2.11
Unit Price: USD $2.1109
≥1 USD $2.1109
≥10 USD $1.73185
≥100 USD $1.6777
≥500 USD $1.62355
≥1000 USD $1.5694
Inventory: 87
Minimum: 1
-
+
Technical Details
Technical
Current Rating 4A
Contact Finish Silver
Termination Style PC Pin
Voltage - Rated AC 125V
Actuator Type Standard
Circuit DPDT
Switch Function On-On
Max Voltage Rating (AC) 250V
Max Current Rating 10A
Electrical Life 10,000 Cycles
Max Voltage Rating (DC) 30V
Contact Timing Not Specified
Depth 16.5mm
Orientation Straight
Current Rating (Amps) 10A AC 4A DC
Voltage - Rated DC 30V
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature O - Marking
Series V
Published 2008
Packaging Tray
Operating Temperature -30°C~85°C
Dimensions
Length 26.19mm
Actuator Length 7.36mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Actuator Material Polyester, Glass Filled
Housing Material Nylon
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper
Supply Chain
Factory Lead Time 16 Weeks
