L203031MS02Q
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
Switch Slide DP3T Extended Top Slide 4A 250VAC 125VDC PC Pins Thru-Hole
PDF
/
Buying Options
Total Price: USD $2.96
Unit Price: USD $2.959277
≥1 USD $2.959277
≥200 USD $1.146162
≥500 USD $1.105462
≥1000 USD $1.085768
Inventory: 5046
Minimum: 1
-
+
Technical Details
Technical
Operating Temperature -30°C~65°C
Packaging Bulk
Published 2013
Series L
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Voltage - Rated DC 28V
Current Rating (Amps) 4A AC/DC
Orientation Straight
Depth 10.8mm
Current Rating 4A
Contact Finish Silver
Termination Style PC Pin
Voltage - Rated AC 125V
Actuator Type Standard
Circuit DP3T
Switch Function On-On-On
Max Voltage Rating (AC) 250V
Max Current Rating 4A
Electrical Life 10,000 Cycles
Max Voltage Rating (DC) 125V
Contact Timing Not Specified
Switch Travel 4.06mm
Dimensions
Length 23.9mm
Actuator Length 9.53mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Actuator Material Polyamide (PA66), Nylon 6/6
Housing Material Nylon
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper
Supply Chain
Factory Lead Time 14 Weeks
