L102021MS02BE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
Switch Slide SPDT Extended Top Slide 20VAC 20VDC 0.4VA PC Pins Thru-Hole
PDF
/
Buying Options
Total Price: USD $9.9
Unit Price: USD $9.897953
≥1 USD $9.897953
Inventory: 3884
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Actuator Length 8.51mm
Length 19.3mm
Technical
Switch Travel 3.81mm
Contact Timing Not Specified
Max Voltage Rating (DC) 20V
Throw Configuration SPDT
Electrical Life 10,000 Cycles
Max Voltage Rating (AC) 20V
Switch Function On-On
Circuit SPDT
Actuator Type Standard
Voltage - Rated AC 20V
Termination Style PC Pin
Contact Finish Gold
Depth 10.79mm
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Min Operating Temperature -30°C
Max Operating Temperature 65°C
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series L
Published 2008
Packaging Bulk
Operating Temperature -30°C~65°C
Physical
Actuator Material Polyamide (PA66), Nylon 6/6
Housing Material Nylon
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Contact Material Copper
Supply Chain
Factory Lead Time 14 Weeks
