JS102011SCQN
RoHS
RoHS compliant
RoHS compliantPackage SMD/SMT
Category Switches / Slide Switches
Description
Switch Slide SPDT Top Slide 0.3A 30VDC Gull Wing SMD T/R
PDF
/
Buying Options
Total Price: USD $0.84
Unit Price: USD $0.836
≥1 USD $0.836
≥10 USD $0.80168
≥100 USD $0.749408
≥500 USD $0.65076
≥1000 USD $0.59217
≥3000 USD $0.548979
Inventory: 1153
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material Copper Alloy
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SMD/SMT
Housing Material Nylon
Actuator Material Polyamide (PA46), Nylon 4/6
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2012
Series JS
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Gull Wing
Number of Positions 2
Voltage - Rated DC 6V
Current Rating (Amps) 300mA DC
Orientation Straight
Depth 7.5mm
Current Rating 300mA
Contact Finish Silver
Termination Style Gull Wing
Actuator Type Standard
Circuit SPDT
Switch Function On-On
Contact Resistance 70mOhm
Max Current Rating 300mA
Electrical Life 5,000 Cycles
Max Voltage Rating (DC) 30V
Contact Current Rating 300mA
Contact Timing Not Specified
Life (Cycles) 5000 cycles
Dimensions
Height 5.5mm
Length 8.5mm
Actuator Length 2.00mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
