ES22MABE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
SWITCH SLIDE DPST 0.4VA 20V
PDF
/
Buying Options
Total Price: USD $8.26
Unit Price: USD $8.2632
≥1 USD $8.2632
≥10 USD $7.8892
≥100 USD $7.175872
≥500 USD $6.6143
Inventory: 101
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Actuator Length 3.07mm
Length 10.03mm
Technical
Switch Travel 2.29mm
Contact Timing Not Specified
Mechanical Life 40,000 Cycles
Max Voltage Rating (DC) 20V
Throw Configuration DPDT, DPST
Electrical Life 40,000 Cycles
Max Voltage Rating (AC) 20V
Contact Resistance 50mOhm
Switch Function On-Off
Circuit DPST
Actuator Type Standard
Voltage - Rated AC 20V
Termination Style PC Pin
Contact Finish Gold
Depth 15.17mm
Orientation Right Angle
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Termination PC Pins
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals, IP57
Series ES
Published 2006
Packaging Tray
Operating Temperature -30°C~85°C
Physical
Actuator Material Liquid Crystal Polymer (LCP)
Housing Material Nylon
Mounting Type Through Hole, Right Angle
Mount Brackets, Through Hole
Contact Material Bronze
Supply Chain
Factory Lead Time 16 Weeks
