AYZ0102AGRL
RoHS
/
Package /
Category Switches / Slide Switches
Description
SWITCH SLIDE SPDT 100MA 12V
PDF
/
Inventory: 1831
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Actuator Length 1.00mm
Width 1.29mm
Length 7.2mm
Technical
Contact Timing Not Specified
Contact Current Rating 100mA
Mechanical Life 10,000 Cycles
Max Voltage Rating (DC) 12V
Throw Configuration SPDT
Max Current Rating 100mA
Switch Function On-On
Circuit SPDT
Actuator Type Standard
Termination Style Gull Wing
Contact Finish Silver
Current Rating 100mA
Depth 5.3mm
Orientation Right Angle
Current Rating (Amps) 100mA DC
Voltage - Rated DC 12V
Min Operating Temperature -10°C
Max Operating Temperature 60°C
Termination Gull Wing
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series AYZ
Published 2008
Packaging Cut Tape (CT)
Operating Temperature -10°C~60°C
Physical
Actuator Material Polyamide (PA66), Nylon 6/6, Glass Filled
Housing Material Glass
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Plating Silver
Contact Material Copper Alloy
