1201M2S3CRE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
SWITCH SLIDE DPDT 6A 120V
PDF
/
Buying Options
Total Price: USD $7.4
Unit Price: USD $7.403443
≥1 USD $7.403443
≥200 USD $2.866061
≥500 USD $2.764967
≥1000 USD $2.715077
Inventory: 1132
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper
Contact Plating Gold, Silver, Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Stainless Steel
Actuator Material Polyamide (PA), Nylon
Technical
Operating Temperature -30°C~65°C
Packaging Bulk
Published 2012
Series 1000
Feature Black Actuator, Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pins
Power Rating 400mW
Voltage - Rated DC 28V
Current Rating (Amps) 6A AC/DC
Orientation Straight
Depth 11.43mm
Current Rating 6A
Contact Finish Gold
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Standard
Circuit DPDT
Switch Function On-On
Max Voltage Rating (AC) 250V
Max Current Rating 6A
Electrical Life 40,000 Cycles
Max Voltage Rating (DC) 28V
Contact Current Rating 3A
Illumination Type Non-Illuminated
Contact Timing Not Specified
Switch Travel 2.16mm
Dimensions
Length 12.7mm
Actuator Length 5.08mm
Compliance
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
