1201M1S4ZBE2

C&K
RoHS
RoHS RoHS compliant
Package /
Category Switches / Slide Switches
Description Switch Slide ON None ON DPDT Extended Top Slide 20VAC 20VDC 0.4VA Solder Lug Panel Mount
PDF
/
Buying Options
Total Price: USD $16.58
Unit Price: USD $16.584553
≥1 USD $16.584553
Inventory: 3663
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Actuator Length 7.24mm
Length 19.56mm

Technical

Switch Travel 2.16mm
Contact Timing Not Specified
Max Voltage Rating (DC) 20V
Throw Configuration DPDT
Electrical Life 100,000 Cycles
Max Voltage Rating (AC) 20V
Switch Function On-On
Circuit DPDT
Actuator Type Standard
Voltage - Rated AC 20V
Termination Style Solder Lug
Contact Finish Gold
Depth 11.43mm
Orientation Straight
Current Rating (Amps) 0.4VA AC/DC
Voltage - Rated DC 20V
Min Operating Temperature -30°C
Max Operating Temperature 65°C
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Black Actuator, Epoxy Sealed Terminals
Series 1000
Published 2012
Packaging Bulk
Operating Temperature -30°C~65°C

Physical

Actuator Material Polyamide (PA), Nylon
Housing Material Stainless Steel
Mounting Type Panel Mount
Mount Panel, Solder
Contact Plating Gold
Contact Material Copper

Supply Chain

Factory Lead Time 16 Weeks
