1101M2S3CGE1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
Switch Slide ON None ON SPDT Top Slide 6A 250VAC 28VDC 0.4VA PC Pins Thru-Hole
PDF
/
Buying Options
Total Price: USD $7.34
Unit Price: USD $7.339111
≥1 USD $7.339111
Inventory: 8107
Minimum: 1
-
+
Technical Details
Technical
Published 2012
Series 1000
Feature Epoxy Sealed Terminals, White Actuator
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
Max Operating Temperature 65°C
Min Operating Temperature -30°C
Voltage - Rated DC 28V
Current Rating (Amps) 6A AC/DC
Orientation Straight
Depth 6.6mm
Current Rating 6A
Contact Finish Gold
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Standard
Circuit SPDT
Switch Function On-On
Max Voltage Rating (AC) 250V
Max Current Rating 6A
Electrical Life 40,000 Cycles
Throw Configuration SPDT
Max Voltage Rating (DC) 28V
Contact Timing Not Specified
Switch Travel 2.16mm
Packaging Bulk
Operating Temperature -30°C~65°C
Dimensions
Length 12.7mm
Actuator Length 5.08mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Actuator Material Polyamide (PA), Nylon
Housing Material Stainless Steel
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Contact Material Copper
Supply Chain
Factory Lead Time 16 Weeks
