1101M1S5ZQE2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
Switch Slide ON None ON SPDT Extended Top Slide 6A 250VAC 28VDC Solder Lug Panel Mount
PDF
/
Buying Options
Total Price: USD $6.4
Unit Price: USD $6.3976
≥1 USD $6.3976
≥10 USD $6.10368
≥100 USD $5.55104
≥500 USD $4.79556
≥1000 USD $4.359582
≥3000 USD $4.039869
Inventory: 90
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Copper
Mount Panel, Solder
Mounting Type Panel Mount
Housing Material Stainless Steel
Actuator Material Polyamide (PA), Nylon
Technical
Operating Temperature -30°C~65°C
Packaging Bulk
Published 2012
Series 1000
Feature Black Actuator, Epoxy Sealed Terminals
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Voltage - Rated DC 28V
Current Rating (Amps) 6A AC/DC
Orientation Straight
Depth 6.6mm
Current Rating 6A
Contact Finish Silver
Termination Style Solder Lug
Voltage - Rated AC 120V
Actuator Type Standard
Circuit SPDT
Switch Function On-On
Max Voltage Rating (AC) 250V
Max Current Rating 6A
Electrical Life 40,000 Cycles
Max Voltage Rating (DC) 28V
Contact Timing Not Specified
Switch Travel 2.16mm
Dimensions
Length 19.56mm
Actuator Length 9.40mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
