SLB23804
RoHS
/
Package /
Category Switches / Slide Switches
Description
SWITCH SLIDE MINI
PDF
/
Inventory: 2626
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Brackets, Through Hole
Mounting Type Through Hole
Insulation Material PHENOLIC
Housing Material STEEL
Actuator Material Thermoplastic
Technical
Operating Temperature -20°C~85°C
Packaging Bulk
Series SLB
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
Number of Positions 3
HTS Code 8536.50.90.50
Voltage - Rated DC 30V
Current Rating (Amps) 300mA AC/DC
Orientation Straight
Contact Finish Silver
Termination Style PC Pin
Body Length or Diameter 17.8mm
Body Breadth 6.2 mm
Actuator Type Standard
Circuit DP3T
Switch Function On-On-On
Contact Resistance 20mOhm
Insulation Resistance 100000000Ohm
Contact Current(DC)-Max 0.3A
Sealing EPOXY TERMINAL SEALED
Max Voltage Rating (AC) 125V
Dielectric Withstanding Voltage 500VRMS V
Electrical Life 10,000 Cycles
Max Voltage Rating (DC) 30V
Switch Type SLIDE SWITCH
Operating Force 220gf
Contact Current(AC)-Max 0.3A
Contact (AC) Max Rating R Load .3A@125VAC
Contact Timing Not Specified
PCB Hole Count 12
Switch Travel 3.20mm
Solderability WAVE
Washability SOLVENT
Dimensions
Body Height 5.5mm
Length - Termination 0.138 inch
Actuator Length 4.00mm
Compliance
RoHS Status Non-RoHS Compliant
