SLB22814
RoHS
/
Package /
Category Switches / Slide Switches
Description
SWITCH SLIDE DPDT 300MA 125V
PDF
/
Inventory: 9424
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Actuator Length 4.00mm
Length - Termination 0.102 inch
Body Height 5.5mm
Technical
Washability SOLVENT
Solderability WAVE
Switch Travel 3.20mm
PCB Hole Count 6
Contact (DC) Max Rating R Load .3A@30VDC
Contact Timing Not Specified
Contact (AC) Max Rating R Load .3A@125VAC
Contact Current(AC)-Max 0.3A
Operating Force 220gf
Contact Current Rating 300mA
Switch Type SLIDE SWITCH
Max Voltage Rating (DC) 30V
Electrical Life 10,000 Cycles
Dielectric Withstanding Voltage 500VRMS V
Max Voltage Rating (AC) 125V
Sealing EPOXY TERMINAL SEALED
Contact Current(DC)-Max 0.3A
Insulation Resistance 100000000Ohm
Contact Resistance 20mOhm
Switch Function On-On
Circuit DPDT
Actuator Type Standard
Body Breadth 6.2 mm
Body Length or Diameter 14mm
Voltage - Rated AC 125V
Termination Style PC Pin
Contact Finish Silver
Current Rating 300mA
Orientation Straight
Current Rating (Amps) 300mA AC/DC
Voltage - Rated DC 30V
HTS Code 8536.50.90.50
Number of Positions 2
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Epoxy Sealed Terminals
JESD-609 Code e4
Series SLB
Packaging Tube
Operating Temperature -20°C~85°C
Physical
End Contact Material BRASS
Terminal Material BRASS
Center Contact Material BRASS
Actuator Material Thermoplastic
Housing Material STEEL
Insulation Material PHENOLIC
Mounting Type Through Hole
Mount Through Hole
