25549NA
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
SWITCH SLIDE DPDT 4A 125V
PDF
/
Buying Options
Total Price: USD $37.02
Unit Price: USD $37.021154
≥1 USD $37.021154
≥200 USD $14.771438
≥500 USD $14.277788
≥1000 USD $14.034901
Inventory: 1189
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 2.30mm
Length - Termination 0.15 inch
Body Height 8.1mm
Technical
Washability PARTIAL
Solderability WAVE
Switch Travel 4.00mm
Contact Function ON-ON
PCB Hole Count 6
Contact Timing Not Specified
Switch Type SLIDE SWITCH
Mechanical Life 20,000 Cycles
Electrical Life 10,000 Cycles
Dielectric Withstanding Voltage 1000VRMS V
Sealing EPOXY TERMINAL SEALED
Contact Current(DC)-Max 1A
Insulation Resistance 1000000000Ohm
Contact Resistance 0.01mOhm
Switch Function On-Off-On
Circuit DPDT
Actuator Type Standard
Body Breadth 12.5 mm
Body Length or Diameter 14.1mm
Voltage - Rated AC 125V
Termination Style PC Pin
Current Rating 1A
Orientation Right Angle
Packing Method BULK
Current Rating (Amps) 4A AC 1A DC
Voltage - Rated DC 30V
HTS Code 8536.50.90.50
Number of Positions 2
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Sealed Terminals
Series 25000N
Packaging Tube
Operating Temperature -40°C~85°C
Physical
End Contact Plating GOLD
Terminal Material BRASS
Center Contact Plating GOLD
Actuator Material Polyamide (PA), Nylon, Glass Filled
Housing Material GLASS FILLED NYLON
Insulation Material THERMOPLASTIC
Mounting Type Through Hole, Right Angle
Mount Through Hole
Contact Material Silver (Ag)
Supply Chain
Factory Lead Time 9 Weeks
