PTL30-15RR-103B1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Slide Potentiometers
Description
Linear Bulk Standard LED Top Slide Potentiometer ±20% 9mm 10kOhms 55C
PDF
/
Inventory: 2505
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Technical
Packaging Bulk
Published 2011
Series Pro Audio PTL
Size / Dimension Rectangular - 1.772Lx0.354W x 0.276 H 45.00mmx9.00mmx7.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Pin
Type Potentiometer
Resistance 10kOhms
Max Operating Temperature 55°C
Min Operating Temperature -10°C
Composition Potentiometer
Power (Watts) 0.1W 1/10W
Power Rating 100mW
Max Power Dissipation 100mW
Depth 9mm
Base Part Number PTL30
Military Standard Not
Adjustment Type Top
Taper Linear
Travel Range 30mm
Fader Type Standard, LED
Dimensions
Height 7.0104mm
Length 45.0088mm
Width 8.9916mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
