PSM01-081A-103A3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Potentiometers, Variable Resistors / Slide Potentiometers
Description
8533.40.80.70 Tray Motor CARBON FILM Slide Potentiometer ±20% 35.0012mm 10kOhm 55C
PDF
/
Inventory: 3564
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 35.0012mm
Technical
Fader Type Motor
Travel Range 100mm
Ganging Number 1
Actuator Orientation VERTICAL
Adjustment Type Top
Working Voltage 10V
Operating Temperature (Min) -10°C
Actuator Type SLIDE
Operating Temperature (Max) 55°C
Rated Power Dissipation (P) 0.25W
Base Part Number PSM01
Reach Compliance Code not_compliant
Resistor Type POTENTIOMETER
Technology CARBON FILM
Max Power Dissipation 250mW
Subcategory Other Resistors
HTS Code 8533.40.80.70
Power (Watts) 0.25W 1/4W
Terminal Finish Tin (Sn)
Resistance 10kOhm
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Size / Dimension Rectangular - 5.984Lx0.512W x 1.378 H 152.00mmx13.00mmx35.00mm
Series Pro Audio PSM
Published 2011
Packaging Tray
Physical
Terminal Shape WIRE
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 20 Weeks
