2671/29RD-1000
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Single Conductor Cables (Hook-Up Wire)
Description
HOOK-UP STRND 29AWG RED 1000'
PDF
/
Inventory: 9589
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Physical
Insulation Material PVC
Conductor Material Copper, Bare
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Technical
Operating Temperature -40°C~80°C
Packaging Spool
Published 2002
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Max Operating Temperature 80°C
Min Operating Temperature -40°C
Color Red
Wire Gauge 29 AWG
Voltage 300V
Cable Type Hook-Up
Wire/Cable Type Hook-Up
Wire/Cable Gauge 29 AWG
Jacket Color Red
Conductor Strand 51/46
Jacket (Insulation) Diameter 0.032 (0.81mm)
Insulation Diameter 812.8 μm
Dimensions
Length 1000.0' 304.8m
Jacket (Insulation) Thickness 0.008 0.20mm
Insulation Thickness 203.2μm
Compliance
RoHS Status ROHS3 Compliant
Ratings UL Style 1692/1568
