39X1635 WH001
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Single Conductor Cables (Hook-Up Wire)
Description
HOOK-UP STRND 16AWG WHITE 1000'
PDF
/
Buying Options
Total Price: USD $5905.63
Unit Price: USD $5905.6272
≥1 USD $5905.6272
Inventory: 97
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Conductor Material Copper, Silver Coated
Jacket (Insulation) Material Silicone Rubber
Technical
Operating Temperature -40°C~200°C
Packaging Spool
Published 2011
Feature Biological Compatibility
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Wire Gauge 16 AWG
Voltage 35kV
Connector Support Type WIRE AND CABLE
Cable Type Hook-Up
Jacket Color White
Conductor Strand 41/32
Jacket (Insulation) Diameter 0.269 (6.83mm)
Dimensions
Length 1000.0' 304.8m
Jacket (Insulation) Thickness 0.105 2.67mm
Compliance
RoHS Status ROHS3 Compliant
Ratings ISO 10993
