VL-EBX-37F
RoHS
/
Package /
Category Embedded Computers / Single Board Computers (SBCs)
Description
SBC CORE II DUO 1.2 GHZ MAX 8GB
PDF
/
Inventory: 7449
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Analog Input:Output 8:4
RS-232 (422, 485) 4
Cooling Type Fan + Heat Sink
Digital I/O Lines 32
Expansion Site/Bus PC/104-Plus
Video Outputs VGA, LVDS (2)
Storage Interface SATA2 (2), eUSB, MiniBlade
RAM Capacity/Installed 8GB/0GB
Number of Analog Inputs 8
Number of Cores 2
Form Factor EBX
USB USB 2.0 (6)
Ethernet GbE (2)
Watchdog Timer Yes
Core Processor Core 2 Duo P8400
Frequency 1.2GHz
Max Power Dissipation 14.3W
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 5.75 x 8 146mmx203mm
Series Mamba
Published 2012
Operating Temperature -40°C~85°C
