ARK-1123C-S3A1E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Embedded Computers / Single Board Computers (SBCs)
Description
FANLESS PC ATOM E3825 1.33GHZ
PDF
/
Inventory: 5894
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
RS-232 (422, 485) 2
Cooling Type Heat Sink
Expansion Site/Bus Mini-PCIe
Video Outputs VGA
Storage Interface SATA HDD, mSATA
RAM Capacity/Installed 8GB/0GB
Number of Cores 2
USB USB 2.0 (2), USB 3.0 (1)
Ethernet 10/100/1000Mbps
Watchdog Timer Yes
Core Processor Atom E3825
Speed 1.33GHz
Frequency 1.33GHz
Min Operating Temperature -30°C
Max Operating Temperature 70°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 5.27 x 3.71 133.8mmx94.2mm
Published 2017
Operating Temperature -30°C~70°C
Supply Chain
Factory Lead Time 12 Weeks
