93512442Y733
RoHS
/
Package 1616 (4040 Metric)
Category Capacitors / Silicon Capacitors
Description
CAP SILICON 3.3UF 15% 11V 1616
PDF
/
Inventory: 8922
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 3.9878mm
Length 3.9878mm
Height 0.010 0.25mm
Technical
ESL (Equivalent Series Inductance) 100pH
Voltage - Breakdown 11V
ESR (Equivalent Series Resistance) 100mOhms
Case Code (Imperial) 1616
Case Code (Metric) 4040
Capacitance 3.3μF
Applications Wirebond and Embedded
Min Operating Temperature -55°C
Max Operating Temperature 200°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Feature High Reliability, Low Profile
Tolerance ±15%
Size / Dimension 0.157Lx0.157W 4.00mmx4.00mm
Series ETSC
Published 2012
Packaging Cut Tape (CT)
Operating Temperature -55°C~200°C
Physical
Package / Case 1616 (4040 Metric)
