SNT-100-BK-G
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Shunts, Jumpers
Description
SAMTEC SNT-100-BK-G JUMPER, 2WAY, 2.54MM
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.2728
≥1 USD $0.2728
≥10 USD $0.2112
≥100 USD $0.176
≥500 USD $0.1496
≥1000 USD $0.1144
≥3000 USD $0.1056
Inventory: 27710
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness 10.0μin 0.25μm
Length 5.08mm
Height 0.240 6.10mm
Technical
Insertion Force-Max 8.896 N
Contact Pattern RECTANGULAR
Max Current Rating 2.5A
Body/Shell Style PLUG
Contact Resistance 5mOhm
Number of Contacts 2
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Depth 2.54mm
Orientation Straight
Pitch 0.100 2.54mm
Current Rating (Amps) 4.3A per Contact
Subcategory Other Interconnects
HTS Code 8536.69
Additional Feature GLASS FILLED POLYESTER
Gender Female Sockets
Number of Rows 1
Color Black
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Type Open Top
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series SNT
Published 2008
Packaging Bulk
Physical
Number of Positions or Pins (Grid) 2 (1 x 2)
Housing Material Polybutylene Terephthalate (PBT)
Contact Material Bronze
Supply Chain
Factory Lead Time 3 Weeks
