M7765-46

Harwin Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Shunts, Jumpers
Description Headers & Wire Housings JUMPER SKT LT GREY CLOSED TOP
PDF
/
Inventory: 5228
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0

Dimensions

Plating Thickness 118μin
Contact Finish Thickness 118.1μin 3.00μm
Height 0.248 6.30mm

Technical

Contact Pattern RECTANGULAR
Durability 50 Cycles
Body/Shell Style PLUG
Insulation Resistance 1000000000Ohm
Contact Resistance 30mOhm
Body Depth 0.248 inch
Operating Temperature (Min) -40°C
Body Breadth 0.091 inch
Operating Temperature (Max) 85°C
Body Length or Diameter 0.197 inch
Reliability COMMERCIAL
Contact Finish Tin
Reference Standard UL
Number of Conductors ONE
Total Number of Contacts 2
Pitch 0.100 2.54mm
Current Rating (Amps) 3A
Subcategory Other Interconnects
Additional Feature ROHS COMPLIANT
Voltage - Rated 250V
Gender Female Sockets
Number of Rows 1
Color Gray
Type Closed Top
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series M77
Published 2014
Packaging Bulk

Physical

Number of Positions or Pins (Grid) 2 (1 x 2)
Mounting Style STRAIGHT
Mounting Option 1 LOCKING
Housing Material Polyester, Glass Filled
Contact Material PHOSPHOR BRONZE

Supply Chain

Factory Lead Time 13 Weeks
