M7566-05
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Shunts, Jumpers
Description
JUMPER, 2WAY, 2.54MM - More Details
PDF
/
Buying Options
Total Price: USD $0.3
Unit Price: USD $0.2992
≥1 USD $0.2992
≥10 USD $0.2552
≥100 USD $0.224576
≥500 USD $0.206272
≥1000 USD $0.198176
≥3000 USD $0.177936
Inventory: 1098
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material Bronze
Insulation Material Polyester
Material Glass, Polyester
Housing Material Polyester, Glass Filled
Weight 45.359237g
Number of Positions or Pins (Grid) 2 (1 x 2)
Technical
Packaging Bulk
Series M75
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Open Top
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Red
Number of Rows 1
Gender Female Sockets
HTS Code 8536.69.80.00
Subcategory Other Interconnects
Pitch 0.100 2.54mm
Orientation Straight
Depth 2.3mm
Current Rating 3A
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Lead Pitch 2.54mm
Number of Contacts 2
Contact Gender Female
Rated Current (Signal) 3A
Contact Style SQ PIN-SKT
Contact Resistance 20mOhm
Insulation Resistance 1GOhm
Body/Shell Style PLUG
Max Voltage Rating (AC) 250V
Max Current Rating 3A
Durability 300 Cycles
Max Voltage Rating (DC) 250V
Contact Pattern RECTANGULAR
Dimensions
Height 0.248 6.30mm
Length 6.3mm
Width 5mm
Contact Finish Thickness 5.11μin 0.130μm
Plating Thickness 5μin
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
