AKSPLT-G-BLK
RoHS
/
Package /
Category Connectors, Interconnects / Shunts, Jumpers
Description
AVAILABLE IN 30micro-inch GOL Shunt
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.087336
≥1 USD $0.087336
≥10 USD $0.034848
≥100 USD $0.033683
≥500 USD $0.033108
Inventory: 6181
Minimum: 1
-
+
Technical Details
Physical
Contact Material PHOSPHOR BRONZE
Mount Slot
Housing Material Polybutylene Terephthalate (PBT)
Number of Positions or Pins (Grid) 2 (1 x 2)
Technical
Packaging Bulk
Published 2005
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Open Top, Grip
Color Black
Number of Rows 1
Gender Female Sockets
Additional Feature AVAILABLE IN 30 micro-inch GOL
Subcategory Other Interconnects
Current Rating (Amps) 3A
Pitch 0.100 2.54mm
Total Number of Contacts 2
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 0.197 inch
Operating Temperature (Max) 105°C
Body Breadth 0.1 inch
Operating Temperature (Min) -40°C
Body Depth 0.177 inch
Contact Style SQ PIN-SKT
Insulation Resistance 5000000000Ohm
Body/Shell Style PLUG
Dielectric Withstanding Voltage 500VAC V
Contact Pattern RECTANGULAR
Dimensions
Height 0.531 13.50mm
Compliance
Material Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
