MS2B-G
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Shunts, Jumpers
Description
MINI SHUNT 2.0MM 2P GOLD
PDF
/
Buying Options
Total Price: USD $0.09
Unit Price: USD $0.088
≥1 USD $0.088
≥10 USD $0.0616
≥100 USD $0.050688
≥500 USD $0.046816
≥1000 USD $0.04532
≥3000 USD $0.039037
Inventory: 11455
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness Flash
Height 0.138 3.50mm
Technical
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 1000VAC V
Insulation Resistance 5000000000Ohm
Contact Resistance 20mOhm
Operating Temperature (Min) -40°C
Operating Temperature (Max) 105°C
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL, CSA
Number of Conductors ONE
Pitch 0.079 2.00mm
Current Rating (Amps) 1A
Subcategory Other Interconnects
Voltage - Rated 250VAC
Gender Female Sockets
Number of Rows 1
Color Black
Type Open Top
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series MS
Packaging Bulk
Physical
Number of Positions or Pins (Grid) 2 (1 x 2)
Mounting Style STRAIGHT
Housing Material Polybutylene Terephthalate (PBT), Glass Filled
Contact Material PHOSPHOR BRONZE
Supply Chain
Factory Lead Time 9 Weeks
