30608
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Sensor Interface - Junction Blocks
Description
ASNBV 8/LED 5-278/10 M
PDF
/
Inventory: 8000
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material COPPER ZINC
Mounting Type BOARD AND PANEL
Insulation Material GLASS FILLED POLYAMIDE
Shell Material ZINC ALLOY
Mounting Option 1 LOCKING
Mounting Style STRAIGHT
Technical
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
Connector Type CIRCULAR CONNECTOR
Additional Feature GLASS FILLED PA
HTS Code 8536.69.40.20
Subcategory DIN Connectors
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 8
Reach Compliance Code not_compliant
Shell Finish NICKEL PLATED
Reference Standard UL
Reliability COMMERCIAL
Operating Temperature (Max) 85°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender FEMALE
Operating Temperature (Min) -40°C
Empty Shell NO
Body Depth 0.559 inch
Rated Current (Signal) 5A
Backshell Type SOLID
Contact Style RND PIN-SKT
Contact Resistance 5mOhm
Insulation Resistance 10000000000Ohm
Body/Shell Style SOCKET
Termination Type SOLDER
Polarization Key POLARIZED HOUSING
Coupling Type THREADED
Number of Ports 1
Insertion Force-Max 4.8928 N
Withdrawl Force-Min 1.1954 N
Dimensions
Plating Thickness FLASH inch
Length - Termination 0.138 inch
Compliance
RoHS Status RoHS Compliant
