3195
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Sensor Cable - Accessories
Description
DC MICR MZR INT THD PNL CAP PIN
PDF
/
Inventory: 1608
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Termination 0.118 inch
Plating Thickness FLASH inch
Technical
Contact Pattern RECTANGULAR
Accessory Type Cap (Cover), Sealing
Durability 50 Cycles
Dielectric Withstanding Voltage 600VAC V
Termination Type SOLDER
Mating Contact Pitch 0.1 inch
Insulation Resistance 1000000000Ohm
Contact Resistance 20mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.189 inch
Operating Temperature (Min) -40°C
Contact Gender MALE
Body Breadth 0.1 inch
Operating Temperature (Max) 105°C
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 1
Body Length or Diameter 1.9 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Reach Compliance Code unknown
Terminal Pitch 2.54mm
Total Number of Contacts 19
Contact Finish - Mating AU ON NI
Subcategory Headers and Edge Type Connectors
Number of Rows 1
Connector Type BOARD CONNECTOR
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series DC Metal Micro-Mizer?
Physical
Mounting Style RIGHT ANGLE
Insulation Material THERMOPLASTIC
Mounting Type BOARD
Contact Material BRASS
Supply Chain
Factory Lead Time 8 Weeks
