19296
RoHS
RoHS compliant
RoHS compliantPackage /
Category Sensors, Transducers / Sensor Cable - Accessories
Description
MINI MIZER PLASTIC PANEL CAP
PDF
/
Buying Options
Total Price: USD $23.1
Unit Price: USD $23.1
≥1 USD $23.1
Inventory: 42
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Material PHOSPHOR BRONZE
Mounting Type CABLE
Insulation Material POLYBUTYLENE TEREPHTHALATE
Mounting Option 1 LOCKING
Technical
Series Mini-Mizer?
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type BOARD EURO CONNECTOR
Number of Rows 3
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating SN
DIN Conformance YES
Total Number of Contacts 96
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 3.74 inch
Operating Temperature (Max) 105°C
Contact Gender FEMALE
Operating Temperature (Min) -40°C
Body Depth 0.453 inch
Contact Style SQ PIN-SKT
Contact Resistance 30mOhm
Insulation Resistance 1000000000Ohm
Mating Contact Pitch 0.1 inch
Termination Type IDC
Polarization Key POLARIZED HOUSING
Accessory Type Cap (Cover), Sealing
Mating Contact Row Spacing 0.1 inch
Contact Design PREASSEM CONN
Name of Rows Loaded A,B,C
Compliance
RoHS Status ROHS3 Compliant
