RoHS
/
Package /
Category Switches / Selector Switches
Description
Standard Reliant'22 3 Panel Mount Selector Switch 6A 600V 6A@600VAC 60deg
PDF
/
Inventory: 1852
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Actuator Color BLACK
Index Angle 60 deg
Contact Voltage(AC)-Max 600V
Contact Timing DOUBLE BREAK
Contact (AC) Max Rating R Load 6A@600VAC
Contact Current(AC)-Max 6A
Illumination Non-Illuminated
Contact Voltage(DC)-Max 120V
Contact Current(DC)-Max 1.1A
Panel Cutout Dimensions Circular - 22.00mm Dia
Switch Function On-On-On
Operating Temperature (Min) -20°C
Operating Temperature (Max) 70°C
Voltage - Rated AC 120V
Reach Compliance Code unknown
Ingress Protection IP65 - Dust Tight, Oil and Water Resistant
Current Rating (Amps) 6A AC
Additional Feature CONTACT BLOCKS SEP. SUPPLIED
Number of Positions 3
Type Standard
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Series Reliant'22
Published 2004
Physical
End Contact Material SILVER
Center Contact Material SILVER
Insulation Material POLYCARBONATE
Mounting Type Panel Mount
Mount Panel
