0033.3522
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Selector Switches
Description
Line Voltage Selector SWZ 6 Panel Mount Selector Switch 14.5mm 10A 250V 10A@250VAC
PDF
/
Buying Options
Total Price: USD $25.05
Unit Price: USD $25.0536
≥1 USD $25.0536
≥10 USD $19.44272
≥100 USD $16.5198
Inventory: 122
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Panel
Mounting Type Panel Mount
Weight 11.600001g
Technical
Operating Temperature -40°C~85°C
Series SWZ
JESD-609 Code e3/e2
Feature Marking: 110-220
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Solder
ECCN Code EAR99
Type Line Voltage Selector
Number of Positions 6
Terminal Finish TIN/TIN COPPER
Voltage - Rated 250V
Current Rating (Amps) 10A AC
Packing Method BULK
Ingress Protection IP40
Depth 24mm
Current Rating 10A
Termination Style Solder, Quick Connect - 0.110 (2.8mm)
Voltage - Rated AC 250V
Approval Agency CSA, UR, VDE
Circuit Series, Parallel Connections
Switch Function On-On-On-On-On-On
Panel Cutout Dimensions Circular - 30.00mm Dia
Illumination Non-Illuminated
Mechanical Life 300 Cycles
Contact (AC) Max Rating R Load 10A@250VAC
Contact (DC) Max Rating R Load 10A@250VDC
Index Angle 30 deg
Number of Switch Sections 1
Depth Behind Flange 21.50mm
Dimensions
Length 47mm
Width 35mm
Body Height 14.5mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
