0033.1500
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Selector Switches
Description
SWITCH SELECT 6POS SP6T 6.3A
PDF
/
Inventory: 1377
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Panel
Mounting Type Panel Mount
Technical
Operating Temperature -40°C~70°C
Packaging Bulk
Series SWK
JESD-609 Code e3/e2
Feature Marking: 110-125-150-200-220-250
Part Status Obsolete
Moisture Sensitivity Level (MSL) Vendor Undefined
Termination Solder
ECCN Code EAR99
Type Line Voltage Selector
Number of Positions 6
Terminal Finish TIN/TIN COPPER
Voltage - Rated 250V
Current Rating (Amps) 6.3A AC
Ingress Protection IP40
Depth 32.5mm
Current Rating 6.3A
Termination Style Solder Lug
Voltage - Rated AC 250V
Approval Agency CSA, SEMKO, UR
Circuit SP6T
Switch Function On-On-On-On-On-On
Panel Cutout Dimensions Circular - 30.00mm Dia
Illumination Non-Illuminated
Mechanical Life 300 Cycles
Number of Switch Sections 1
Depth Behind Flange 28.50mm
Dimensions
Length 47mm
Width 35mm
Body Height 28.5mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
