SF2039B
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD, No Lead
Category Filters / SAW Filters
Description
Signal Conditioning 72.54MHz, SDARS IF SAW Filter
PDF
/
Buying Options
Total Price: USD $3.17
Unit Price: USD $3.1654
≥1 USD $3.1654
≥10 USD $2.5973
≥100 USD $2.5156
≥500 USD $2.43485
≥1000 USD $2.3541
Inventory: 5085
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status TO BE DISCONTINUED (Last Updated: 4 weeks ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 10-SMD, No Lead
Technical
Packaging Tape & Reel (TR)
Size / Dimension 0.276Lx0.197W 7.00mmx5.00mm
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Applications SDARS
Voltage - Rated 30V
Frequency 72.54MHz
Bandwidth 4MHz
Insertion Loss 10.5dB
Insertion Loss (dB) 10.5 dB
Frequency - Cutoff or Center 72.54MHz
Load Impedance 1kOhm
Dimensions
Height 2.0066mm
Length 7.0104mm
Width 5.0038mm
Height (Max) 0.079 2.00mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
