RF1V-4A2BL-D24

IDEC
RoHS
RoHS RoHS compliant
Package /
Category Relays / Safety Relays
Description RELAY GEN PURPOSE 6PST 6A 24V
PDF
/
Buying Options
Total Price: USD $29.47
Unit Price: USD $29.4712
≥1 USD $29.4712
≥10 USD $27.99896
≥100 USD $26.525312
≥500 USD $25.051664
≥1000 USD $23.578104
≥3000 USD $22.104474
Inventory: 73
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 4 Weeks

Physical

Contact Material Silver Tin Oxide (AgSnO)
Mount PCB, Plug-In
Mounting Type Through Hole
Number of Pins 14

Technical

Operating Temperature -40°C~85°C
Packaging Bulk
Published 2009
Series RF1V
Feature Lighted Indicator
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination PC Pin
ECCN Code EAR99
Depth 2.0066mm
Current Rating 15mA
Termination Style PC Pin
Voltage - Rated AC 8.333V
Approval Agency CSA, TUV, UL
Number of Poles 6
Throw Configuration DPST
Response Time 8 ms
Contact Form 6PST-4NO/2NC (4 Form A, 2 Form B)
Relay Type General Purpose
Fall Time (Typ) 20 ms
Coil Resistance 1.15kOhm
Coil Voltage 24VDC
Switching Voltage 250VAC 30VDC -Max
Coil Current 20.8mA
Must Operate Voltage 18VDC
Contact Rating (Current) 6A
Coil Power 500mW
Must Release Voltage 2.4VDC
Coil Voltage (DC) 24V

Dimensions

Height 24mm
Length 50mm
Width 13mm

Compliance

RoHS Status ROHS3 Compliant
