711-5-T2E
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
Flatted (6.35mm Dia) 711 SP5T 2 Rotary Switch 12.70mm 7A 125V 5.041-8.641gfm
PDF
/
Buying Options
Total Price: USD $635.26
Unit Price: USD $635.255855
≥1 USD $635.255855
≥200 USD $253.4711
≥500 USD $245.001582
≥1000 USD $240.816057
Inventory: 4632
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 12.70mm
Technical
Switch Action LATCHED
Angle of Throw 30°
Number of Poles per Deck 1
Number of Switch Sections 2
Depth Behind Panel 45.20mm
Circuit per Deck SP5T
Index Stops Fixed
Contact Timing Non-Shorting (BBM)
Contact Current(AC)-Max 7A
Operating Force 5.041 ~ 8.641gfm
Number of Decks 2
Switch Type ROTARY SWITCH
Contact Current(DC)-Max 7A
Panel Cutout Dimensions Circular - 9.53mm Dia
Actuator Type Flatted (6.35mm Dia)
Body Length or Diameter 39.6mm
Voltage - Rated AC 125V
Termination Style Solder, Quick Connect - 0.187 (4.7mm)
Current Rating (Amps) 7A AC/DC
Voltage - Rated DC 20V
Number of Positions 5
ECCN Code EAR99
Termination Lug
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series 711
Published 2007
Packaging Bulk
Physical
Surface Mount NO
Mounting Type Panel Mount
Contact Material Silver Alloy
Supply Chain
Factory Lead Time 12 Weeks
