412-5
RoHS
/
Package /
Category Switches / Rotary Switches
Description
Rotary Switches 5 TAPS 50A/300VAC 20VDC
PDF
/
Inventory: 7304
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Actuator Length 28.58mm
Technical
Switch Action LATCHED
Angle of Throw 30°
Number of Switch Sections 1
Index Angle 120 °
Depth Behind Panel 61.90mm
Circuit per Deck SP5T
Index Stops Fixed
Contact Voltage(AC)-Max 300V
Contact Timing Non-Shorting (BBM)
Operating Force 35 ~ 92gfm
Number of Decks 1
Switch Type ROTARY SWITCH
Contact Voltage(DC)-Max 20V
Actuator Type Flatted (6.35mm Dia)
Voltage - Rated AC 300V
Termination Style Solder Lug
Current Rating (Amps) 50A AC/DC
Voltage - Rated DC 20V
Number of Positions 5
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code no
Series 412
Packaging Bulk
Physical
Surface Mount NO
Mounting Type Panel Mount
Contact Material Silver Alloy
