312-12
RoHS
/
Package /
Category Switches / Rotary Switches
Description
OHMITE 312-12 SWITCH, ROTARY TAP, SP12T, 30A, 300V
PDF
/
Buying Options
Total Price: USD $222.09
Unit Price: USD $222.0856
≥1 USD $222.0856
≥10 USD $208.6304
≥100 USD $200.55376
≥500 USD $183.728864
≥1000 USD $174.979904
Inventory: 22
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Contact Material Silver Alloy
Contact Plating Silver
Mount Panel
Mounting Type Panel Mount
Technical
Published 2007
Series 312
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
ECCN Code EAR99
Number of Positions 12
HTS Code 8536.50.90.25
Voltage - Rated DC 20V
Current Rating (Amps) 30A AC/DC
Orientation Vertical
Current Rating 30A
Termination Style Solder Lug
Voltage - Rated AC 300V
Body Length or Diameter 84mm
Actuator Type Flatted (6.35mm Dia)
Contact Style Non-Shorting
Switch Type ROTARY SWITCH
Contact Current Rating 30A
Number of Decks 1
Operating Force 35 ~ 81gfm
Illumination Type Illuminated, Non-Illuminated
Contact (AC) Max Rating R Load 30A@300VAC
Contact Timing Non-Shorting (BBM)
Index Stops Fixed
Circuit per Deck SP12T
Depth Behind Panel 57.20mm
Index Angle 15 °
Number of Switch Sections 1
Angle of Throw 30°
Switch Action LATCHED
Dimensions
Body Height 57.2mm
Actuator Length 28.58mm
Compliance
REACH SVHC Unknown
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
