54A01112S-A01112S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
SWITCH ROTARY 12POS 1A 115V
PDF
/
Buying Options
Total Price: USD $296.1
Unit Price: USD $296.09965
≥1 USD $296.09965
≥200 USD $118.146558
≥500 USD $114.198668
≥1000 USD $112.247698
Inventory: 2882
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Silver Alloy
Mount Panel
Mounting Type Panel Mount
Number of Pins 12
Technical
Series 54
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Number of Positions 12
Voltage - Rated DC 28V
Current Rating (Amps) 1A AC/DC
Current Rating 1A
Termination Style Solder Lug
Voltage - Rated AC 115V
Actuator Type Concentric (3.17mm Dia, 6.35mm Dia)
Contact Style Shorting
Number of Decks 1
Operating Force 5.761 ~ 83gfm
Contact Timing Shorting (MBB)
Index Stops Continuous
Circuit per Deck SP12T
Depth Behind Panel 46.18mm
Index Angle 30 °
Number of Poles per Deck 1
Angle of Throw 30°
Dimensions
Actuator Length 9.53mm
Compliance
RoHS Status RoHS Compliant
