50CPT36-01A10S
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
Flatted (3.17mm Dia) 50 SP10T 1 Rotary Switch 9.53mm 150mA AC 200mA DC 220V 5.761-17gfm
PDF
/
Inventory: 2326
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Contact Material Metal
Mount Panel, Through Hole
Mounting Type Panel Mount, Through Hole
Technical
Series 50
Feature Process Sealed
Part Status Active
Termination PC Pins
Number of Positions 10
Voltage - Rated DC 28V
Current Rating (Amps) 150mA AC 200mA DC
Contact Finish Gold
Termination Style PC Pin
Voltage - Rated AC 115V
Actuator Type Flatted (3.17mm Dia)
Max Voltage Rating (AC) 220V
Throw Configuration SP10T
Max Voltage Rating (DC) 28V
Number of Decks 1
Operating Force 5.761 ~ 17gfm
Contact Timing Shorting (MBB)
Index Stops Continuous
Circuit per Deck SP10T
Depth Behind Panel 14.63mm
Number of Poles per Deck 1
Angle of Throw 36°
Dimensions
Actuator Length 9.53mm
Compliance
RoHS Status RoHS Compliant
