E4C0905N
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
SWITCH ROTARY 2-5POS 9A 115V
PDF
/
Buying Options
Total Price: USD $1349.73
Unit Price: USD $1349.73341
≥1 USD $1349.73341
≥200 USD $538.552893
≥500 USD $520.55566
≥1000 USD $511.663388
Inventory: 2371
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Actuator Length 47.63mm
Technical
Index Angle 20 °
Depth Behind Panel 88.21mm
Circuit per Deck 3P5T
Index Stops Adjustable
Contact Timing Non-Shorting (BBM)
Number of Decks 3
Contact Style Non-Shorting
Panel Cutout Dimensions Circular - 9.78mm Dia
Actuator Type Flatted (6.35mm Dia)
Voltage - Rated AC 115V
Termination Style Solder Lug
Current Rating 11A
Current Rating (Amps) 9A AC 11A DC
Voltage - Rated DC 28V
Number of Positions 2 ~ 5
Termination Solder
Part Status Active
Series E4
Published 2006
Physical
Number of Pins 5
Mounting Type Panel Mount
Mount Panel
Contact Material Silver (Ag)
Supply Chain
Factory Lead Time 5 Weeks
