E2G0402S-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
SWITCH ROTARY 2POS 500MA 115V
PDF
/
Inventory: 2669
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Actuator Length 16.27mm
Technical
Angle of Throw 30°
Number of Poles per Deck 4
Index Angle 30 °
Depth Behind Panel 33.34mm
Circuit per Deck 4PDT
Index Stops Fixed
Contact Timing Shorting (MBB)
Number of Decks 1
Throw Configuration 4PDT
Number of Poles 4
Contact Style Shorting
Actuator Type Lever
Voltage - Rated AC 115V
Termination Style Solder Lug
Contact Finish Silver
Current Rating 1.5A
Depth 33.3502mm
Current Rating (Amps) 500mA AC 1.5A DC
Voltage - Rated DC 28V
Number of Positions 2
Termination Solder
Part Status Active
Feature Spring Return
Series E2
Published 2006
Physical
Mounting Type Panel Mount
Mount Panel
Contact Plating Silver
Contact Material Brass
