D7G0111N
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Rotary Switches
Description
Rotary Switches 2-11 POS/1 P/1 DECK
PDF
/
Inventory: 919
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Actuator Length 47.63mm
Technical
Angle of Throw 30°
Number of Poles per Deck 1
Index Angle 30 °
Depth Behind Panel 16.76mm
Circuit per Deck SP11T
Index Stops Adjustable
Contact Timing Non-Shorting (BBM)
Number of Decks 1
Mechanical Life 25000 cycles
Max Voltage Rating (DC) 28V
Throw Configuration SP11T
Number of Poles 1
Max Voltage Rating (AC) 115V
Insulation Resistance 750GOhm
Contact Resistance 3mOhm
Contact Style Non-Shorting
Panel Cutout Dimensions Circular - 9.78mm Dia
Actuator Type Round (6.35mm Dia)
Voltage - Rated AC 115V
Termination Style Solder Lug
Contact Finish Silver
Current Rating 2.25A
Depth 16.764mm
Orientation Straight
Current Rating (Amps) 1A AC 2.25A DC
Voltage - Rated DC 28V
Number of Positions 2 ~ 11
Termination Solder
Part Status Active
Series D7
Published 1997
Physical
Mounting Type Panel Mount
Mount Panel
Contact Plating Silver
Contact Material Brass
Supply Chain
Factory Lead Time 8 Weeks
